CE-0972 ETHERNET WIDGET

This is the latest in the Widget series that expands on the CE0872 and adds an SD memory slot as standard. Along with an on-board real-time clock this makes this unit suitable for logging purposes and with the optional Ethernet port adds remote accessiblity. There is so much packed into this one tiny unit that we can’t catagorize it, just think of it as a configurable embedded communications PC. The uses for this are diverse and as simple as a TV terminal or an RS-232 datalogger or as a control processor in a datacommunications environment.

- P8X32A Multicore CPU (8 x 32)
- RS232 DB9 DTE – 8 signals
- 1200 to 460.8K baud
- RS422/485 opeation to 1M baud
- USB serial port (non-isolated)
- VGA/TV/Audio RJ45 combo
- SD memory slot
- Real-time clock
- Six status indicators
- 10 to 28VDC operation
- 70mm height x 79mm depth
- 25mm wide DIN RAIL mount
Options
- 10/100base-T
- 4MB on-board Dataflash
- MicroSD or standard SD
- SMF Optical Fiber Transciever
- Dual 2 amp “open-collector” outputs

Applications
- SERIAL DATA LOGGER
- MULTI-PROTOCOL HUB/CONTROLLER
- VT100 OPERATOR TERMINAL
- STAND-ALONE CONTROLLER
- PROTOCOL LOGGING & DIAGNOSTICS
- INTERNET ACCESS GATEWAY
- MODBUS HOST or SLAVE
- VIDEO+AUDIO ANNUNCIATOR
- INFORMATION TERMINAL
- GPS LOGGING and DISPLAY
configuration

2 x RS485 or RS422 port or OC outputs RS-232 DTE or 5 receive + 3 transmits VGA/TV (standard) or Fiber option PS/2 or module expansion port TTL serial port (standard) or LAN option
